Specifications
| MODEL | BH3130071 | BH3130072 | BH3130081 | BH3130082 |
| DESCRIPTION | Manual Single 20Amp Switch 120- 277V Indoor Kit |
Manual Dual 20Amp Switch 120- 277V Indoor Kit |
Manual Single 20Amp Switch 120- 277V Outdoor Kit |
Manual Dual 20Amp Switch 120- 277V Outdoor Kit |
| AMPERAGE | 20 A | 20 A | 20 A | 20 A |
| Dielectric Voltage | Withstands 1500V for 1 min. | Withstands 1500V for 1 min. | Withstands 1500V for 1 min. | Withstands 1500V for 1 min. |
| ENDURANCE | 50,000 cycles minimum | 50,000 cycles minimum | 50,000 cycles minimum | 50,000 cycles minimum |
| GROUNDING | Self-Grounding | Self-Grounding | Self-Grounding | Self-Grounding |
| TEMPERATURE RISE | Maximum 30 degrees C rise | Maximum 30 degrees C rise | Maximum 30 degrees C rise | Maximum 30 degrees C rise |
| VOLTAGE | 120/277 VAC | 120/277 VAC | 120/277 VAC | 120/277 VAC |
| OPERATING TEMPERATURE | -40°C to 65°C | -40°C to 65°C | -40°C to 65°C | -40°C to 65°C |
| SWITCH COLOR | WHITE | WHITE | WHITE | WHITE |
| WALL PLATE COLOR | WHITE | WHITE | GREY | GREY |
